Features:

GH – Low-Headroom Hoists

• Optimized for confined lifting spaces
• Available with flat or angled wheels to match your bottom flange and running profile
• Designed for smooth operation and extended hoist lifespan

Features:

GH – Standard-Headroom Hoists

• Ideal for general-purpose lifting where space is ample
• Suitable for 1/1 and 2/2 reeving systems
• Available with flat or angled wheels for improved performance and durability

Features:

GH – Compact Hoists

• Extremely compact design for optimal space utilization
• Suitable for multiple industrial and manufacturing applications
• Engineered for durability, reliability, and easy maintenance

Features:

GH – Hoists on End Trucks

• Configurable for dual-hoist and rotating trolley systems
• Designed for end-truck and special lifting applications
• Optional features include manual brake release, weighing system, and additional safety brake

Features:

• Two speed pole-change hoisting motor with bimetal sensor
• Hoist D.C disc brake, maintenance free, with 4-step gear limit switches (up, down, low speed up approach, phase fault protection)
• Electromechanic overload protection
• Variable speed travelling motor: 3 to 20 m/min (hoist with trolley)
• Standard power supply: 380V / 400V / 415V / 50Hz; 440V / 460V / 60Hz
• Motor protection IP55, insulation class F
• Without push button box
• Hook with safety latch
• Rubber buffers (for hoist with trolley)

Features:

• Two speed pole-change hoisting motor with bimetal sensor
• Hoist D.C disc brake, maintenance free, with 4-step gear limit switches (up, down, low speed up approach, phase fault protection)
• Electromechanic overload protection
• Variable speed travelling motor: 3 to 20 m/min (hoist with trolley)
• Standard power supply: 380V / 400V / 415V / 50Hz; 440V / 460V / 60Hz
• Motor protection IP55, insulation class F
• Without push button box
• Hook with safety latch
• Rubber buffers (for hoist with trolley)

Hoist Features:

• Lifting Capacity: 10 to 20 Tons
• Lifting Height: 6–18 Meters
• Power Supply: 220–460V, 50/60Hz, 3 Phase
• Sling Type: Wire Rope
• Lifting Speed: 5 / 0.8 m/min
• Travel Speed: 20 / 5 m/min
• Hook: Forged Steel
• Quality: Built with advanced German technology for precision and durability
• Reliability: Equipped with ABM gearbox and motor for consistent performance
• Production: Economically manufactured in China with strict quality standards

Features:

• Most suitable for use on Duobeam
• Available in standard range up to 108 metric tons
• For special design as a custom built hoist up to 500 metric tons

Features:

• Low headroom monorail hoist for maximum lifting height use on MONOBEAM Crane
• Available in wide range up to 55 metric tons

Features:

• A universal that can be placed on a bearing surface
• Available range up to 9 metric tons on a single fall of wire rope
• Available with any of 5 different hoist drums

Features:

• A smart solution to achieve better headroom using a top running trolley on a single girder crane
